Cement Concrete Brick Shot Blasting Surface Treatment Machine

PRO cement concrete brick shot blasting surface treatment machine is the most advanced model designed and manufactured in China. With top-tier components like SEW gearboxes, Siemens motors, and Schneider electrical parts, our machines offer unparalleled durability and performance. We also provide tailored solutions to meet the specific needs of our clients, ensuring that each machine is optimized for maximum efficiency and quality.

Produktparameter (Spezifikation)

Merkmale

1.Umweltverträglichkeit:

The PRO Shot Blasting Machine enhances the value and eco-friendliness of cement bricks. It effectively improves the surface quality without harming the environment.

2.Kompaktes und zuverlässiges Design:

Our cement concrete brick shot blasting surface treatment machine features a compact structure that ensures stable operation. It is designed for long-term durability, providing both safety and reliability during work.

3. Pitless-Design für einfache Installation:

Dank des grubenlosen Designs ist die Maschine einfach zu installieren und bietet eine flexible Integration in sekundäre Behandlungslinien für Zementsteine.

Anwendung

PRO’s cement concrete brick shot blasting surface treatment machine is primarily used for surface treatment in the production of stone materials. It is ideal for Marble, granite, artificial stone, PC bricks, curbstones, and floor tiles. It is used to remove rust, oxide scales, sand residues, and contaminants from surfaces, while improving the surface friction for enhanced slip resistance.

The machine also enhances flatness and texture, making it suitable for use in high-safety and aesthetic applications such as plazas, building facades, indoor halls, and urban walkways.

Additionally, the cement concrete brick shot blasting surface treatment machine supports surface strengthening for concrete products and metal plates, offering an environmentally friendly alternative to traditional flame or acid treatment methods. With its high efficiency, compact design, and recyclable abrasive system, the PRO Shot Blasting Machine has a minimal environmental impact.

Produktionsdetails

Unsere Zementbeton-Ziegelstrahl-Oberflächenbehandlungsmaschine besteht aus den folgenden Komponenten:

1. Reinigungskammer

The chamber is made from welded steel plates, designed to accommodate large workpieces. It includes a sealed cavity with wear-resistant guard plates to enhance durability and reduce maintenance costs.

2.Förderband

Featuring welded steel pipe shafts for smooth operation, the belt’s speed is adjustable through a frequency converter, allowing for customized surface cleaning speeds.

3. Strahlanlage

Comprising impellers, blades, and a shot distribution wheel, the shot blasting unit accelerates steel shot, achieving high-speed impacts for optimal surface treatment.

4.Elevator

A bucket elevator, designed with a welded shell, efficiently lifts the shot-dust mixture from the cleaning chamber to the top of the machine, ensuring smooth and reliable operation.

5.Separator

Der BE-Typ-Separator sortiert das Stahlgranulat effizient, optimiert die Lebensdauer der Messer und verbessert die Gesamtleistung der Maschine Leistung.

6.Schneckenförderer

Der Schneckenförderer sammelt das Schrot-Staub-Gemisch und leitet es zum Elevator, wodurch eine effiziente Verarbeitung gewährleistet wird.

7. Staubsammler

Equipped with an MC64 bag filter, this dust collector minimizes dust emissions to below 0.06 mg/m³, ensuring a clean and environmentally friendly operation.

Warum PRO wählen?

1. Erfahrung: Mit über 20 Jahren Erfahrung ist PRO ein vertrauenswürdiger Hersteller und Lieferant von Strahlmaschinen in China.
2. Qualität: Wir verwenden erstklassige Komponenten wie SEW-Getriebe, Siemens-Motoren und elektrische Teile von Schneider überlegene Leistung.
3.Anpassung: Wir bieten maßgeschneiderte Lösungen basierend auf Ihren spezifischen Anforderungen, um die besten Ergebnisse zu gewährleisten.
4.Environmental Friendliness: Our machines are designed to reduce environmental impact while delivering efficient and high-quality results.

PRO's commitment to quality, technology, and customer satisfaction makes us the number one choice for Shot Blasting Surface Treatment Machines in China.
